High-Performance Thermal Infrastructure
The EVM-Series high-pressure vertical steam boiler line delivers optimal multi-phased thermal output capacities spanning from 30 kg/hr to 1000 kg/hr. Engineered explicitly for intense industrial environments, these heavy-duty systems feature multi-element combustion controllers, specialized feed-water arrangements, and optimized fluid dynamics to prevent localized heat stress and drop occurrences during heavy manufacturing operations.
Our vertical utility solutions incorporate meticulous internal water wall distribution configurations and flue gas economizers to guarantee maximum heat recovery. Review the physical dimension sets, operational kilowatts per hour indicators, and sizing variables within the engineering matrix below to isolate the appropriate model for your infrastructure requirement:
- Advanced Multiphase Quality Control System, 100% Operational Safety Uptime Guarantee
- Unrivalled Structural Steel Workmanship, Conducted by Professional and Certified Engineers
- High Thermal Efficiency Design with Specialized Eco-Friendly Low Carbon Calibration Paths
| Model No. | Capacity (kg/hr) | Heater (kw/hr) | A | B | C | D | E | F | G | Inlet Size | Outlet Size |
|---|---|---|---|---|---|---|---|---|---|---|---|
| EVM - 030 | 30 | 4.5 | 890 | 1055 | 1150 | 470 | 435 | 670 | 150 | 20A (3/4") | 20A (3/4") |
| EVM - 050 | 50 | 7.5 | 890 | 1055 | 1150 | 470 | 435 | 670 | 150 | 20A (3/4") | 20A (3/4") |
| EVM - 100 | 100 | 15 | 1040 | 1205 | 1300 | 470 | 435 | 670 | 150 | 20A (3/4") | 25A (1") |
| EVM - 150 | 150 | 22.5 | 1040 | 1220 | 1320 | 530 | 495 | 730 | 188 | 20A (3/4") | 25A (1") |
| EVM - 200 | 200 | 30 | 1030 | 1210 | 1310 | 670 | 635 | 880 | 180 | 20A (3/4") | 25A (1") |
| EVM - 300 | 300 | 22.5x2 | 1180 | 1360 | 1460 | 610 | 575 | 810 | 180 | 20A (3/4") | 25A (1") |
| EVM - 400 | 400 | 30x2 | 1100 | 1300 | 1400 | 730 | 695 | 985 | 240 | 25A (1") | 50A (2") |
| EVM - 500 | 500 | 25x3 | 1200 | 1400 | 1505 | 730 | 695 | 985 | 240 | 25A (1") | 50A (2") |
| EVM - 600 | 600 | 30x3 | 1300 | 1500 | 1605 | 790 | 755 | 1040 | 240 | 25A (1") | 50A (2") |
| EVM - 700 | 700 | 35x3 | 1300 | 1500 | 1605 | 950 | 900 | 1245 | 312.5 | 25A (1") | 50A (2") |
| EVM - 800 | 800 | 40x3 | 1360 | 1560 | 1665 | 950 | 900 | 1245 | 312.5 | 40A (1 1/2") | 80A (3") |
| EVM - 900 | 900 | 45x3 | 1430 | 1630 | 1760 | 1065 | 1015 | 1375 | 345 | 40A (1 1/2") | 80A (3") |
| EVM - 1000 | 1000 | 50x3 | 1500 | 1700 | 1830 | 1105 | 1075 | 1375 | 345 | 40A (1 1/2") | 80A (3") |
